Specification

  • SKU: A-V/E-10b
  • Working distance : 30m
  • Operating principle : on/off. Dim
  • Ingress protection : IP20
  • Colour : White
  • Warranty : 5 years
  • Output mode : Single colour or CCT
  • Control signal : 2.4 GHz RF
  • Zones : 1
  • Battery : CR2032 (3 V)
  • Working temperature : −10…+40 °C
  • Standby power consumption : 6 µA
  • Transmitting power : 6 dBm
  • Modulation : GFSK
  • EMC standard : ETSI EN 301 489-1 V2.2.3 (2019-11); ETSI EN 301 489-3 V2.3.2 (2023-01)
  • Safety standard (LVD) : EN 61347-2-11:2001+A1:2019; EN 61347-1:2015+A1:2021; EN 62493:2015+A1:2022
  • Radio equipment (RED) : ETSI EN 300 440 V2.2.1 (2018-07)
  • Certification : CE (EMC, RED)

Fizinės savybės

  • Length: 86 mm
  • Width: 86 mm
  • Height: 27 mm
